Firstly, find out the factors that affect the safety of ringlock scaffolding. There are three main aspects: one is the safety and reliability of ringlock scaffolding itself, the second is the safety protection measures of ringlock scaffolding, and the third is the safe operation of ringlock scaffolding. Let's take a look separately.

Ruggedness and stability are the safe and reliable foundation of ringlock scaffolding. Under allowable load and weather conditions, the structure of ringlock scaffold must be stable without shaking, shaking, tilting, sinking, or collapsing.
To ensure the safety and reliability of ringlock scaffolding, the following basic requirements should be ensured:

Powered by Shandong Unique International Trade Co.,Ltd

1) The frame structure is stable.
The frame unit shall be of a stable structure; the frame body shall be provided with diagonal rods, shear braces, wall rods, or bracing and pulling parts as required. In the passages, openings, and other parts that need to increase the structural size (height, span) or bear the specified load, strengthen the rods or braces according to the needs. Unique

2) The connection node is reliable.
The cross position of the rods must meet the requirements of the node structure; the installation and fastening of the connectors meet the requirements. The connecting wall points, support points and suspension (hanging) points of the disc-buckle scaffolding must be set at the structural parts that can reliably bear the support and tension load, and the structure check calculation should be carried out if necessary. Shandong Unique International Trade Co.,Ltd

3) The foundation of the disc scaffold should be firm and firm. https://www.3plyplywood.com

Unique

Safety protection of disc scaffolding

The safety protection on the ringlock scaffold is to use safety facilities to provide safety protection to prevent people and objects on the rack from falling. Specific measures include: Copyright © Shandong Unique International Trade Co.,Ltd All Rights Reserved.

1) Ringlock scaffolding Shandong Unique International Trade Co.,Ltd

(1) Safety fences and warning signs should be set up on the job site to prohibit irrelevant personnel from entering the dangerous area.

Copyright © Shandong Unique International Trade Co.,Ltd All Rights Reserved.

(2) Temporary supports or knots should be added to the ringlock scaffolding parts that have not been formed or have lost structural stability.

(3) When using a seat belt, a safety rope should be pulled when there is no reliable seat belt buckle.

(4) When dismantling the ringlock scaffolding, it is necessary to set uplifting or lowering facilities, and throwing is prohibited. Shandong Unique International Trade Co.,Ltd

(5) Movable ringlock scaffolds such as hoisting, hanging, picking, etc., should be supported and pulled to fix or reduce their shaking after moving to the working position. Unique

2) Operating platform (work surface) Powered by Shandong Unique International Trade Co.,Ltd

(1) Except that 2 scaffolding boards are allowed to be used for decoration ringlock scaffolding with a height of less than 2m, the working surface of other ringlock scaffolding shall not be less than 3 scaffold boards, and there is no gap between the scaffold boards. The gap between the faces is generally not more than 200mm.

Powered by Shandong Unique International Trade Co.,Ltd

(2) When the scaffold board is flat-joined in the length direction, its connecting ends must be tightened, and the small crossbar under its end should be fixed firmly and not floating to avoid sliding. The distance between the center of the small crossbar and the board ends should be Control in the range of 150-200mm. The scaffold boards at the beginning and end of the ring lock scaffold should be reliably bolted to the ringlock scaffold; when lap joints are used, the lap length must not be less than 300mm, and the beginning and end of the scaffold must be fastened firmly.

(3) The protective facilities facing the outer facade of the operation can use scaffolding boards plus two protective railings, three railings plus outer plastic woven cloth (height not less than 1.0m or set according to steps). Two levers are used to tie a bamboo fence with a height of not less than 1m, two railings are fully hung with safety nets or other reliable enclosure methods.

Shandong Unique International Trade Co.,Ltd

(4) The frontage and pedestrian transportation channels:
① Use plastic woven cloth, bamboo fence, mat, or tarpaulin to completely close the street surface of the ringlock scaffolding.
②Hang safety nets on the frontage, and set up safety passages. The top cover of the passage should be covered with scaffolding or other materials that can reliably bear falling objects. The side of the canopy facing the street should be provided with a baffle no less than 0.8m higher than the canopy to prevent falling objects from rebounding onto the street.
③ Pedestrian and transportation passages that are close to or passing through the ringlock scaffolding must be provided with tents.
④The entrance of the upper and lower ringlock scaffolding with a height difference should be provided with ramps or steps and guardrails.
